Borewell Submersible Pump, KP4 JALRAAJ UVA 30-1520, 1.5 HP, Single Phase, 220 Volts, Size 32mm with control panel

The Kirloskar KP4 JALRAAJ UVA 30-1520 is a powerful and energy-efficient 1.5 HP borewell submersible pump, purpose-built for deep water lifting in residential, agricultural, and light commercial applications. This model features a 20-stage multi-impeller system, offering greater head range and steady flow across all conditions.

Its oil-cooled motor ensures smooth operation even during extended hours, while the stainless-steel build resists corrosion and wear, making it ideal for long-term use in borewells across India.

This pump includes a pre-configured control panel, adding extra safety, automation, and ease of use — perfect for first-time and experienced users alike.

Key Features:

• 1.5 HP Oil-Cooled Motor – Strong discharge and reliable for continuous operation
• Wide Voltage Range (150–240V) – Functions reliably in low or fluctuating voltage areas
• 20-Stage Design – Provides higher head and pressure, ideal for deep borewell installations
• Stainless Steel Construction – Corrosion-resistant for long-lasting durability
• Low Noise, Balanced Operation – Dynamically balanced parts reduce vibration and noise
• Compact & Lightweight – Easy to handle, install, and service
• Includes Control Panel – Plug-and-play solution with inbuilt motor protection

Technical Specifications:

• Power: 1.5 HP (1.1 kW)
• Phase: Single Phase
• Voltage Range: 150 – 240 Volts
• Stages: 20
• Pipe Size: 32mm
• Cooling Type: Oil-Cooled
• Protection: IP68 Rated
• Material: Stainless Steel & High-Quality Polymers
• Control Panel: Included
• Applications:
  – Deep Borewell Water Lifting
  – Overhead Tank Supply
  – Drip Irrigation & Garden Use
  – Rural Water Supply
• Warranty: 12 Months Manufacturer Warranty
